Product catalog : Air amplifiers
Description:
OPERATING PRINCIPLE
Through a very fine internal round air nozzle, air movers and air amplifiers release the compressed air introduced into the tube in very small quantities. The airflow then reaches an almost sonic velocity. This ultra-fast air jet creates a strong vacuum behind it, drawing in the surrounding air located behind the air mover or amplifier, while the ambient air is pushed forward.
KEY BENEFITS
No moving parts, no electricity, no risk of sparks or explosions. Air amplifiers can be used in the same way as a vacuum pump, ventilation or blowing system to remove dust, fumes or granular/fibrous materials. The airflow can be easily adjusted using a convenient adjustment ring, without cumbersome shims and without wasting compressed air.
OPERATING DIAGRAM
Operating diagram of AA series air amplifiers
Operating diagram of AA series air amplifiers with flanges and reducers
APPLICATIONS
Variable air amplifiers have been designed for high-volume blowing applications using only a small amount of compressed air.
